75 Inch 3000nits Brightness IP65 Waterproof Outdoor Digital Signage with 4K Resolution and Android OS

MOQ:	1

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Screen Size:

75 Inch

Brightness:

3000 Nits

Resolution:

3840*2160

Panel Type:

IPS

Viewing Angle:

178°

Contrast Ratio:

3000:1

Color Gamut:

Adobe RGB 98%

Response Time:

6 Ms

Operating Temperature:

-20°C To 70°C

Power Consumption:

≥100 W

Weight:

140kg

Material:

Sheet Metal

Protection Grade:

IP65

RAM:

2 GB

ROM:

32 GB

Highlight:

3000nits Brightness Outdoor Digital Signage

75 Inch Size Waterproof LCD Screen

IP65 Waterproof Digital Advertising Board

Product Description

75-Inch 3000nits 4K Vertical Waterproof Outdoor LCD Screen

Professional outdoor digital signage with IPS panel, WiFi hotspot, floor stand, low-temperature heating, and touch capabilities.

Professional Outdoor Digital Signage Solutions

One-stop OEM/ODM customization solutions from LCD modules to complete devices.

Ultra-High Brightness Performance

Brightness range: 2000-3000 nits or higher available with auto-brightness adjustment sensor as standard equipment.

Ensures advertising content remains clearly visible in bright sunlight from dawn to noon, effectively boosting advertising effectiveness.

Rugged Outdoor Protection

All-metal construction with IP65 dust and water resistance, supporting wide temperature operation from -20°C to 70°C.

Operates reliably in torrential rain, sandstorms, or extreme temperatures, significantly reducing maintenance costs and failure rates.

High-Efficiency Heat Dissipation

Utilizes intelligent temperature control system with outdoor unit heat dissipation and internal fan cooling to ensure core components operate at constant temperature.

Energy Efficient & Long-Lasting

Industrial-grade A+ LCD panels with energy-efficient LED backlighting, delivering Mean Time Between Failures (MTBF) of ≥ 50,000 hours.

Lower energy consumption and longer service life provide higher overall return on investment (ROI).

Technical Specifications

Screen Parameters
Model	TX750M-M02
Backlight type	Direct down LED backlight
Active area	165*934mm
Resolution	3840*2160
Color	16.7M
Pixel pitch	0.630×0.630 mm (H×V)
Brightness	2000-3000cd/㎡
Contrast ratio	5000:1
Viewing angle	±178°
Response time	6 (Typ.)(G to G) ms
Dimming mode	Automatic Adjustment / Main Board Adjustment
Heat Dissipation Parameters
Heat dissipation	Air Cooling
Operating temperature	0-50/'-20℃~70℃
Heat dissipation power	100W
Speed control	Auto-adjustment
Protection grade	IP55
Dust filter	Primary filter
Additional Heating	150W/PTC heater option
Shell Parameters
Main structure, Back door, Base material	SGCC hot dip galvanized anti-corrosion sheet + Outdoor powder coating Thickness T=1.5MM
Protective glass	5mm Tempered Glass
Waterproof and anti-theft	Waterproof sealing strip/ Anti-theft lock for connecting rod
Painted color	Outdoor white corrugated, Outdoor gray, Outdoor black corrugated
Mainboard Optional
Display Motherboards (Codename M)	2HDMI-IN(4K@60Hz), USB2.01(for upgrading and playing USB disk content)
Android motherboards (Codename A)	CPU RK3568 Cortex-A17 quad-core up to 1.8GHz, DDR DDR-III 2GB (4GB optional), Storage Default standard 8GB EMMC NAND chip (supports up to 128GB)
Touch Optional
Nano Touch	10-point, metal grid nano-touch
Packaging Dimensions & Weight
Dimension of whole Machine(mm)	2050.168793.8mm (LWT)（Base 500mm）
Gross weight	190kg
Net weight	140kg
Machine life	＞50000 Hrs
Power Supply
Power Input	AC 100V~240V
Maximum power consumption	≦620W
Standby power	<5W

Comprehensive Custom Solutions

Hardware Customization

Size & Form Factor: Standard sizes from 32" to 98", with support for custom shapes (curved, circular), portrait/landscape orientation, wall-mount/ceiling-mount configurations
Brightness and Resolution: Customizable brightness levels and resolutions (1080P to 4K) tailored to application requirements
Touch Functionality: Optional outdoor-grade high-brightness infrared touchscreen with 10-point touch support, featuring anti-vandal and scratch-resistant properties

Software and System Customization

Operating System: Choose from Android, Windows, or Linux systems
Playback Software: Supports custom UI/UX branding for your brand, with optional remote cluster management
Interfaces & Expansion: Customizable interfaces (LAN, COM, HDMI) and add-ons (cameras, microphones, card readers) based on requirements

Packing & Shipping

Versatile packaging solutions for all shapes and sizes
Multiple options for sea, land, and air shipping
Trustworthy and secure wooden crate packaging for extra protection
Professional packing services to ensure proper security during transport

Frequently Asked Questions

Q: Are you a factory?

A: Yes, we are an OEM/ODM manufacturer of indoor & outdoor LCD digital signage in Shenzhen, China.

Q: What's sample production time?

A: Standard models: 2-3 working weeks. Customized projects: 5-6 working weeks.

Q: What's your warranty term?

A: One year warranty under normal use with parts replacement coverage.

Q: What's the outdoor LCD display working temperature range?

A: With air flow cooling system, working temperature -10℃-60℃.

Q: What's your outdoor LCD screen brightness?

A: For outdoor display, we have 1500nits to 5000nits high brightness LCD panel optional.

Q: How to use and install it?

A: We provide user manual and instruction videos for easy installation and use.

Q: What's the packing?

A: Thick foam inside with goods packed into strong plywood wooden box for export delivery safety.
